8

2. Setting up the monitor

2.3 Remove the Base Assembly for

VESA Mounting

Before you start disassembling the monitor

base, please follow the instructions below to

avoid any possible damage or injury.

1. Place the monitor face down on a

smooth surface. Pay attention not

to scratch or damage the screen.

2. Use a athead screwdriver to remove four

mylars from the hinge cover.

1

2

3. Remove the screws from hinge cover.

4. Remove the base assembly.
